帕斯菲达LP系列电磁隔膜计量泵

描述：

美国帕斯菲达电磁隔膜计量泵LP系列

手动：频率、冲程同时调节

流量0.5-95L/小时，压力2-21Bar

自动：可选4-20mA，脉冲信号，液位信号接收功能

21种机型

流量及压力：

LPK2..................0.5L/H................21Bar

LPB2..................0.8L/H...............17Bar

LPD3...................1.9L/H................17Bar

LPF4...................3.2L/H................17Bar

LPH4...................6.4L/H................17Bar

LPA2...................0.9L/H.................10Bar

LPB3...................1.9L/H................10Bar

LPD4....................3.4L/H...............10Bar

LPG4..................6.6L/H.................10Bar

LPK5..................9.5L/H..................10Bar

LPH5..................11.9L/H................10Bar

LPA3....................1.9L/H.................7Bar

LPK3....................2.3L/H.................7Bar

LPB4.....................3.8L/H................ 7Bar

LPE4......................7L/H................... 7Bar

LPG5.....................14.8L/H............... 7Bar

LPH6......................18.9L/H...............7Bar

LPK7......................30.3L/H.............3.3Bar

LPH7......................37.9L/H.............2.4Bar

LPJ8........................75L/H...............2.5Bar

LPH8......................94.6L/H..............2Bar

参数说明：

**可承受物料粘度.................3000CPS

**冲程频率.............................125次/分钟

重复计量精度..............................±3%

冲程调节比.................................10：1

频率调节比.................................10：1

电源............................................220VAC /50HZ

**功率.....................................130W

平均功率......................................50W

环境温度范围...............................0℃-50℃

物料温度范围...............................0℃-70℃

绝缘等级......................................E型绝缘，内置热保护装置

防护等级......................................IP55
